Washing Machine Outlet Boxes & Valves - LSP Products https://www.lspproducts.com/product-category/specialty-products/washing-machine-outlet-boxes-valves/ Mon, 07 Aug 2023 18:51:02 +0000 en-US hourly 1 https://wordpress.org/?v=6.3.2 Condensate Funnel https://www.lspproducts.com/product/condensate-funnel/ Mon, 07 Aug 2023 18:48:18 +0000 https://www.lspproducts.com/?post_type=product&p=9019 Newly designed condensate funnel, with built in air gap.
Left-justified condensate knockouts for 3/4" and 1" IPS piping, is made of polystyrene.

The post Condensate Funnel appeared first on LSP Products.

]]> Newly designed condensate funnel, with built in air gap.
Left-justified condensate knockouts for 3/4″ and 1″ IPS piping, is made of polystyrene.

The post Condensate Funnel appeared first on LSP Products.

]]> The Power Box FireStop Dual Drain Washing Machine Outlet Box https://www.lspproducts.com/product/the-power-box/ Wed, 31 May 2023 13:59:02 +0000 https://www.lspproducts.com/?post_type=product&p=8832 Powerbox is a versatile fire-rated outlet box with right-justified, top-mounted CPVC valves and the choice of left, right, or center drain. Pair with the newly designed condensate funnel, with built in air gap, to utilize the left-justified condensate knockouts for 3/4" and 1" IPS piping.

The post The Power Box FireStop Dual Drain Washing Machine Outlet Box appeared first on LSP Products.

]]> Powerbox is a versatile fire-rated outlet box with right-justified, top-mounted CPVC valves and the choice of left, right, or center drain. Pair with the newly designed condensate funnel, with built in air gap, to utilize the left-justified condensate knockouts for 3/4″ and 1″ IPS piping.

DESIGN FEATURES
• 1hr and 2hr fire rated
• Proven design with fire rating
• Selectable drain orientations
• Integrated knockout test cap
• Deep faceplate accepts up to two sheets of 5/8″ drywall
• Intumescent pad for fire protection
• Box constructed of fire resistant PVC

COMPLIANCES/LISTINGS
• Warnock Hersey listed 1hr and 2hr: ASTM E814, CAN/ULC S115, IAPMO/UPC Certified 0901
• Valve also meets or exceeds: ASME A112.18.1, NSF Standard 61

* Add “-T” to the end of these part numbers for Tract Pack (faceplates packaged separately)
* Add “-TOP” to the end of the part number for Top Mounted valves

The post The Power Box FireStop Dual Drain Washing Machine Outlet Box appeared first on LSP Products.

]]> FireStop™ Washing Machine One Stop Box™ with Hammer Arrester https://www.lspproducts.com/product/firerated-washing-machine-one-stop-box-with-hammer-arresters/ Mon, 04 Feb 2019 19:17:06 +0000 https://www.lspproducts.com/?post_type=product&p=3623 All of the great features of our  FireStop™ Washing Machine One Stop Box™ with Hammer Arrester valves. Rough-in Kit (-RK) includes box, valves and debris cover. Faceplates sold separately.

The post FireStop™ Washing Machine One Stop Box™ with Hammer Arrester appeared first on LSP Products.

]]> The post FireStop™ Washing Machine One Stop Box™ with Hammer Arrester appeared first on LSP Products.

]]> FireStop™ Washing Machine One Stop Box™ https://www.lspproducts.com/product/fire-rated-washing-machine-one-stop-box/ Fri, 01 Feb 2019 07:53:04 +0000 https://www.lspproducts.com/?post_type=product&p=3608 The FireStop™ Washing Machine One Stop Box™ is constructed of fire resistant ABS with a factory installed intumescent pad. The OBFOS series are Warnock Hersey certified to ASTM E-814 and CAN/ULC S115 1 hour and 2 hour listings. Suitable for wood or metal studs and all pipe types. The Fire Rated One Stop Box™ is the only outlet box in its class to be Fire Rated for 2 per stud bay. Rough-in Kit (-RK) includes box, valves and debris cover.  Faceplates sold separately. Dimensions - 7.5"W x 7.8"H x 3.7"D Faceplate - 6.8"W x 7.1"H

The post FireStop™ Washing Machine One Stop Box™ appeared first on LSP Products.

]]> FireStop™ Washing Machine One Stop Box™ is constructed of fire resistant ABS with a factory installed intumescent pad. The OBFOS series are Warnock Hersey certified to ASTM E-814 and CAN/ULC S115 1 hour and 2 hour listings. Suitable for wood or metal studs and all pipe types. The Fire Rated One Stop Box™ is the only outlet box in its class to be Fire Rated for 2 per stud bay.

The post FireStop™ Washing Machine One Stop Box™ appeared first on LSP Products.

]]> Washing Machine One Stop Box™ with Water Hammer Arresters https://www.lspproducts.com/product/washing-machine-one-stop-box-with-water-hammer-arresters/ Mon, 24 Sep 2018 13:53:36 +0000 https://www.lspproducts.com/?post_type=product&p=3203 All of the great features of our Washing Machine One Stop Box™ with Hammer Arrester valves. Rough-in Kit (-RK) includes box, valves and debris cover. Faceplates sold separately. Dimensions - 7.5" W x 7.8" H x 3.7” D Faceplate - 6.8" W x 7.1"H

The post Washing Machine One Stop Box™ with Water Hammer Arresters appeared first on LSP Products.

]]> The post Washing Machine One Stop Box™ with Water Hammer Arresters appeared first on LSP Products.

]]> Washing Machine One Stop Box™ https://www.lspproducts.com/product/washing-machine-one-stop-box/ Wed, 19 Sep 2018 20:38:26 +0000 https://www.lspproducts.com/?post_type=product&p=3188 The smallest single box valves, condensate and drain on the market. Featuring a patented integrated condensate funnel that accommodates 1/2" or 3/4" pipe, that can be installed in the rough in stage and still allow for testing.  Replaceable valves utilize reliable triple o-ring seal, no expense or hassle of cutting drywall required. Included debris cover protects until the finish stage, drain guard to retain slow leaks and integrated mounting system that allows the installer to secure box with nails, screws or hyco straps. Unique simplex handle, universal faceplate and available faceplate extension that is stackable to each additional layer of 5/8" drywall. Rough-in Kit (-RK) includes box, valves and debris cover. Faceplates sold separately. Dimensions - 7.5"W x 7.8"H x 3.7"D Faceplate - 6.8"W x 7.1"H

The post Washing Machine One Stop Box™ appeared first on LSP Products.

]]> The post Washing Machine One Stop Box™ appeared first on LSP Products.

]]> Kahuna™ Outlet Box https://www.lspproducts.com/product/kahuna-outlet-box/ Mon, 27 Mar 2017 13:27:18 +0000 http://s22970.p20.sites.pressdns.com/product/kahuna%c2%99-outlet-box/ One of the most durable outlet boxes in the plumbing industry. Our error-proof, no knockout drains allow for hassle-free testing. Fill your stack directly from the box and test without a mess! Dual drain feature allows you to choose right or left outlet. Easy-to-install cosmetic cap hides unused drain. Optional, innovative condensate, with visible air gap, accommodates secondary drainage where needed. Quarter Turn Ball Valve Outlet Box. Dimensions: 7-1/4" x 9-3/4" x 3-3/4". Faceplate: 12.32" x 8.50".
Add "-T" to the end of the part number for Tract Pack (faceplates packaged separately)
Add "-C" to the end of the part number for Condensate Stand
Add "-P" to the end of part number for two Test Plugs to be included

The post Kahuna™ Outlet Box appeared first on LSP Products.

]]> The post Kahuna™ Outlet Box appeared first on LSP Products.

]]> Kahuna™ Outlet Box with Hammer Arresters https://www.lspproducts.com/product/kahuna-outlet-box-with-hammer-arresters/ Mon, 27 Mar 2017 13:27:18 +0000 http://s22970.p20.sites.pressdns.com/product/kahuna%c2%99-outlet-box-with-hammer-arresters/ All of the great features of our Kahuna™ Outlet Box with Water Hammer Arresters. Outlet box includes a plastic Simplex handle.
Add "-T" to the end of the part number for Tract Pack (faceplates packaged separately)
Add "-C" to the end of the part number for Condensate
Add "-P" to the end of part number for two Test Plugs to be included
*Add "-TOP" to the end of the part number for Top Mounted Valves

The post Kahuna™ Outlet Box with Hammer Arresters appeared first on LSP Products.

]]> The post Kahuna™ Outlet Box with Hammer Arresters appeared first on LSP Products.

]]> Plastic Switch Hitter® Outlet Box https://www.lspproducts.com/product/plastic-switch-hitter-outlet-box/ Mon, 27 Mar 2017 13:27:18 +0000 http://s22970.p20.sites.pressdns.com/product/plastic-switch-hitter-outlet-box/ One box does it all! Patented design provides left, center and right waste options. Knockouts accept either waste or water lines. Quarter Turn Ball Valve. Durable brass resists corrosion. Valves certified to ASME 112.18.1/CSA B125.1 Standard. Long lasting double stem O-rings and tough PTFE seats.
Dimensions: Box: 6-1/2" x 7-5/8" x 3". Faceplate: 10-3/8" x 8-7/16".
Add "-T" to the end of the part number for Tract Pack (faceplates packaged separately)
Add "-TOP" to the end of the part number for Top Mounted Valves

The post Plastic Switch Hitter® Outlet Box appeared first on LSP Products.

]]> The post Plastic Switch Hitter® Outlet Box appeared first on LSP Products.

]]> Plastic Switch Hitter® Outlet Box With Water Hammer Arresters https://www.lspproducts.com/product/plastic-switch-hitter-outlet-box-with-water-hammer-arresters/ Mon, 27 Mar 2017 13:27:18 +0000 http://s22970.p20.sites.pressdns.com/product/plastic-switch-hitter-outlet-box-with-water-hammer-arresters/ All the great features of our Plastic Switch Hitter® Outlet Box with Water Hammer Arresters.
Add "-T" to the end of the part number for Tract Pack (faceplates packaged separately)
Add "-TOP" to the end of the part number for Top Mounted Valves

The post Plastic Switch Hitter® Outlet Box With Water Hammer Arresters appeared first on LSP Products.

]]> The post Plastic Switch Hitter® Outlet Box With Water Hammer Arresters appeared first on LSP Products.

]]>
